    IP40 Max 20A Remote Touch Dimmer , Single Channel Output RF LED controller

    Ask Lasest Price
    Brand Name : JIBANG
    Model Number : DM9125
    Certification : CE/ROHS/EMC/LVD
    Price : Negotiation
    Payment Terms : T/T, Western Union, MoneyGram,PayPal
    Supply Ability : 1000 pieces per month
    Delivery Time : 3-15 days
    • Product Details
    • Company Profile

    IP40 Max 20A Remote Touch Dimmer , Single Channel Output RF LED controller


    Single Channel 433.92MHz RF Wireless LED Controller Touch Dimmer


    SUMIRIZE:


    DM9125 is the single channels product of 433.92MHz RF Wireless LED Dimmer Series. We also have other similar products with 1-4 channels for option. 433MHz is a normal frequence to realize wireless LED lighting controlling which can only reach one-to-one controlling. It can reach 20 meters controlling distance in the open space. It can go cross normal obstacle and satisfy common use in LED lighting. Much more easy to install and operation, beautiful appearance and rich function, this products will be your best choice of LED wireless controller.


    Features:

    This is RF433.92MHz LED dimming controller, using button control mode, the user can according to the actual needs, remotely adjust the light to the appropriate brightness. The remote control effect is stable, and the anti-interference ability is strong. One to one remote control can be realized. This controller is with 8 kinds of dynamic mode effect, 10 dimming function, 256 PWM precision, 10 level dynamic effect of adjustable speed, static adjustable brightness. At the same time, this controller has ultra-thin RF wireless remote control, the ultimate slim body, loop mode, host and remote shutdown, automatic memory function,etc.


    Tech-parameters:


    1, Remote Controller / Touch Dimmer
    Input VoltageDC3V ( CR2032 batteries)
    RFID433.92MHz
    Control ModePress Buttons
    SizeL86*W40*H7(mm)
    Weight40g
    2, Receiver / LED Driver
    Input VoltageDC12-24V
    Output Si9gnalConstant Voltage PWM Signal
    Output Channels1 channel
    Output Current LoadMax 20A
    RFID433.92MHz
    Effective Control Distance30 Meters
    Working Temperature-20~55℃
    SizeL150*W45*H33(mm)
    Weight80g


    Specifications of LED RF Wireless Controller Series:


    Model NO.

    Input

    Voltage

    ChannelsMax Current LoadRF FrequenceMax Output PowerShell Color
    DM9009DC12-24V1CH20A*1CH433.92MHz240W(12V)/480W(24V)Blue
    DM9010DC12-24V2CH10A*2CH433.92MHz240W(12V)/480W(24V)Blue
    CO6001DC12-24V3CH6A*3CH,Max16A433.92MHz216W(12V)/432W(24V)Blue
    DM9121DC12-24V1CH20A*1CH2.4GHz240W(12V)/480W(24V)White
    DM9122DC12-24V2CH10A*2CH2.4GHz240W(12V)/480W(24V)White
    DM9123DC12-24V3CH6A*3CH,Max 18A2.4GHz216W(12V)/432W(24V)White
    DM9124DC12-24V4CH5A*4CH2.4GHz240W(12V)/480W(24V)White
    DM9125DC12-24V1CH20A*1CH433.92MHz240W(12V)/480W(24V)White
    DM9126DC12-24V3CH6A*3CH433.92MHz216W(12V)/432W(24V)White

    Function Instructions:



    1), Press the red button to change the power-on and standby state, plug in the power automatically back to the last shutdown mode, under the state of operation at the same time according to the code, ash express code successfully.

    2), In dynamic mode, press “light”, the controller will change to lighting function.
    3), Press “100%” “50%” “25%” to change the lighting state with brightness of 100% 50% 25%.

    3), In the lighting state press “Mode+” , the controller will change to the dynamic mode.In this mode, press “Mode-” ,it will cycle dynamic effect to adjust transforming speed of dynamic mode, press “speed+” dynamic speed up, press “speed-” dynamic speed slows down.

    4), Adjust the lighting brightness: press “light +”increase the brightness, press “light -” down the brightness.


    Product Wiring Diagram:



    Attentions of DM9123:


    1. Please offer the receiver a input voltage of DC12-24V, not any other voltage.


    2, There is no battery in the new remote controller, please instal a couple of standard AAA Battery before using.


    3, Please correctly connect the line according to the wiring diagram.


    4, This product must not be overloaded.


    5, The 20 meters remote control distance may be shorter in narrow space or somewhere insist many obstacles.
